FD2-12G-D

FD2-12G 防尘倒扳开关

FD2-12G series Dustproof Lever Switches

产品描述Product description

FD2-12G系列是一款专用型的倒扳开关,也叫摇杆开关,集成防尘防水功能,广泛应用于各类台式电动工具,如:台式推拉锯、台式圆锯、台式刨床、台式铣床、台式线锯、台式钻床、台式车床、台式砂轮机、台式瓷砖切割机、地板锯等。
FD2-12G series are special type Lever switches, integrated dustproof and waterproof, commonly for used in bench top power-tools such as Bench Push-pull Saws, Bench Circular Saws, Bench Planers, Bench Routers, Bench Scroll Saws, Drill Presses, Bench lathes, Bench Grinders, Bench Marble Cutters, Floor Cutters, etc.

产品特征Features

◆可选带以下功能 Optional with following function:
→单极单掷 SPST (Single Pole Single Throw)
→单极双掷 SPDT (Single Pole Double Throw)
→单极双掷中间断开 SPDT with center off
→双极单掷 DPST (Double Pole Single Throw)
→双极双掷 DPDT (Double Pole Double Throw)
→双极双掷带中间断开 DPDT with center off
◆可选带以下附件 Optional with following accessory:
→儿童安全锁 Key for children's safety

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥1E5/ 5E4
→电气耐久寿命 Electrical life endurance≥5E4/ 1E4
→最大冲击电流 Max.Inrush current at 250V90A
→最大冲击电流 Max.Inrush current at 125V132A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP54
→适用于II类防护器具 Suitable for appliances of protection class II

端子类型Terminals

◆输入端/输出端 Input side/Output side:
→插片端子 Plug-in terminals 6.3×0.8mm
→插片端子 Plug-in terminals 4.8×0.8mm
→焊接端子 Soldering terminals 4.8×0.8mm
→螺钉端子 Screw terminals M3.5

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
