FDT-2212-P6-T8

FDT滑动(推拉)开关

FDT series Slide (Push-pull) Switches

产品描述Product description

FDT系列是一款通用型的滑动开关,也叫推拉开关或推拨开关,应用于各类需要档位控制的电动工具和小家电,如:热风枪,吹吸机,电吹风等.
FDT series are general type slide switches, commonly for used in power-tools and small home appliances such as Heat Guns, Blowers, Hair Dryers, etc.

产品特征Features

◆可选带以下功能Optional with following function:
→单极两档位电动Single Pole 2 Position
→双极两档位Double Pole 2 Position
→单极两档位点动Single Pole 2 Position Momentary Act
→双极两档位点动Double Pole 2 Position Momentary Act
→单极三档位Single Pole 3 Position
→双极三档位Double Pole 3 Position

技术数据Technical data

→机械耐久寿命Mechanical life endurance≥5E4
→电气耐久寿命Electrical life endurance≥1E4
→最大电流Max.Inrush current at 125V16A
→接触电阻Contact resistance≤30m Ohm
→绝缘电阻Insulation resistance≥7M  Ohm
→基本介电强度Dielectric strength of function500V
→环境温度Ambient temperature0°C~85°C
→阻燃等级FlammabilityUL 94V-0
→防护等级Protection typeIP40
→适用于II类防护器具Suitable for appliances of protection class II

端子类型Terminals

◆输入端/输出端Input side/Output side:
→焊接端子Solder terminals 2.7X0.6mm
→线路板焊接端子PCB Soldering terminals 0.8X0.6mm
→线路板焊接端子PCB Soldering terminals 1. 5X0.6mm

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
