FDT-2314-P5-T1

FDT滑动(推拉)开关

FDT series Slide (Push-pull) Switches

产品描述Product description

FDT系列是一款通用型的滑动开关,也叫推拉开关或推拨开关,应用于各类需要档位控制的电动工具和小家电,如:热风枪、吹吸机、电吹风等。
FDT series are general type slide switches, commonly for used in power-tools and small home appliances such as Heat Guns, Blowers, Hair Dryers, etc.

产品特征Features

◆可选带以下功能 Optional with following function:
→单极两档位动 Single Pole 2 Position
→双极两档位 Double Pole 2 Position
→单极两档位点动 Single Pole 2 Position Momentary Act
→双极两档位点动 Double Pole 2 Position Momentary Act
→单极三档位 Single Pole 3 Position
→双极三档位 Double Pole 3 Position

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥5E4
→电气耐久寿命 Electrical life endurance≥1E4
→最大电流 Max. Inrush current at 125V16A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M  Ohm
→基本介电强度 Dielectric strength of function500V
→环境温度 Ambient temperature0°C~85°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II

端子类型Terminals

◆输入端/输出端 Input side/Output side:
→焊接端子 Solder terminals 2.7×0.6mm
→线路板焊接端子 PCB Soldering terminals 0.8×0.6mm
→线路板焊接端子 PCB Soldering terminals 1.5×0.6mm

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
