FDR series Slide (Push-pull) Switches

产品描述Product description

FDR series are special arc type slide switches, commonly for used in micro current appliances such as DC Cordless Drills, DC Cordless Screwdrivers, DC Cordless Lights, etc.

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大电流 Max. current at 24Vd.c0.5A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function500V
→加强介电强度 Dielectric strength of reinforced500V
→环境温度 Ambient temperature0°C~85°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II


◆输入端/输出端 Input side/Output side:
→焊接端子 Soldering terminals 4-φ=0.8mm
★Utility Model patented with the no. is ZL201821372793.X

电气参数和认证 Electric Rating and Certification
