◆FDK系列是一款通用型的推拉开关，也叫滑动开关，广泛应用于各类需要档位控制的电动工具和小家电，如：热风枪、电吹风等。 ◆FDK series are general type slide switches, commonly for used in power-tools and small home appliances such as Heat Guns, Hair Drvers, etc.
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥5E4 →电气耐久寿命 Electrical life endurance≥1E4 →最大电流 Max. current at 250V10A →接触电阻 Contact resistance≤30m Ohm →绝缘电阻 Insulation resistance≥100M Ohm →基本介电强度 Dielectric strength of function500V →加强介电强度 Dielectric strength of reinforced500V →环境温度 Ambient temperature0°C~85°C →阻燃等级 FlammabilityUL 94V-0 →防护等级 Protection typeIP40 →适用于II类防护器具 Suitable for appliances of protection class II
