FDB-B-C

FDB防尘倒扳开关

FDB series Dustproof Lever Switches

产品描述Product description

FDB系列是一款专用型的倒扳开关,也叫摇杆开关或拨动开关,集成防尘功能,应用于各类电动工具,如:100和125角向磨光机、电木铣、模具电磨等。
FDB series are one special type Lever switch, integrated dustproof, commonly for used in portable power-tools such as 100mm and 125mm Angle Grinders, Routers, Die Grinders, etc.

产品特征Features

◆可选带以下附件 Optional with following accessories:
→防尘套 Dustproof sheath
→安装螺母 Nut for installation

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大冲击电流 Max.Inrush current at 250V48A
→最大冲击电流 Max.Inrush current at 125V72A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M  Ohm
→基本介电强度 Die lectric strength of function1500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP50
→适用于II类防护器具 Suitable for appliances of protection class II

端子类型Terminals

◆输入端/输出端 Input side/Output side:
→插片端子 Plug-in terminals 4.8×0.5mm
→插片端子 Plug-in terminals 4.8×0.8mm
→焊接端子 Soldering terminals 4.8×0.8mm
→螺钉端子 Screw terminals M3.5

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
