FA7-6K-2100-S-X(4-60)-4Y17

FA7-6K(防尘防水)按钮开关

FA7-6K series (Dustproof and waterproof) Push-button Switch

产品描述Product description

FA7-6K系列是一款专用型的按钮开关,应用于各类家用电器和园林工具,如:自动扫地机、智能自动割草机等。
FA7-6K series are special type push-button switch, commonly for used in home appliances or gardening tools such as Automatic Vacuum Cleaners, Smart Automatic Lawnmovers, etc.

产品特征Features

◆可选带以下功能 Optional with following function:
→单极信号常开 Signal Single Pole Normally Open (SSPNO)
→双极信号常开 Signal Double Pole Normally Open (SDPNO)
→单极常开带霍尔信号输出 SPNO with Hall Signal
→双极常开带霍尔信号输出 DPNO with Hall Signal
→带防护罩可实现防尘防水功能 Optional with Protection Cap for dustproof and waterproof

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥3E6
→电气耐久寿命 Electrical life endurance≥3E6
→最大电流 Max. current at 5Vd.c10mA
→接触电阻 Contact resistanceN/A
→绝缘电阻 Insulation resistanceN/A
→基本介电强度 Dielectric strength of functionN/A
→加强介电强度 Dielectric strength of reinforcedN/A
→环境温度 Ambient temperature-25°C~85°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP65
→适用于II类防护器具 Suitable for appliances of protection class II

端子类型Terminals

◆输入端/输出端 Input side/Output side:
→导线端子 Wire terminals
→带插头导线端子 Wire terminals with Plug

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
