产品描述Product description
◆FA7-6G系列是一款小型型的2档位或3档位按钮开关，应用于各类小型低电流电器，如：充电式电筒、玩具、剃须刀等。
◆FA7-6G series are mini-type push-button switch with 2 postion or 3 position, for used in low current appliances such as Rechargeable Lights, Toys or Shavers, etc.
产品特征Features
◆可选带以下功能 Optional with the function as follows:
→单极常开 SPNO (Single Pole Normally Open)
→单极常开带闭合自锁 SPNO with latching
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥5E4
→电气耐久寿命 Electrical life endurance≥1E4
→最大电流 Max. currentat 12Vd.c0.1A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function500V
→加强介电强度 Dielectric strength of reinforced500V
→环境温度 Ambient temperature0°C~85C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→焊接端子 Soldering terminals
电气参数和认证 Electric Rating and Certification
