FA2-5D-2115

FA2-5D防尘按钮开关

FA2-5D series Dustproof Push-button Switches

产品描述Product description

FA2-5D系列是一款专用型的按钮开关,集成防尘功能,应用于各类手持式电动工具,如:125和150角向磨光机、抛光机等。
FA2- 5D series are special type Push-button switch, integrated dustproof, for used in portable power-tools such as 125mm and 150mm Angle Grinders, Polishers Grinders, etc.

产品特征Features

◆可选带以下附件 Optional with the accessories as follows:
→滤波电容(电容值由客户选定,一般为0.22μF或0.33μF)
Suppression capacitor (commonly 0.22 or 0.33μF)

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大冲击电流 Max. Inrush current at 250V60A
→最大冲击电流 Max. Inrush current at 127V90A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M  Ohm
→基本介电强度 Dielectric strength of function1500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP50
→适用于II类防护器具 Suitable for appliances of protection class II

端子类型Terminals

◆输入端 Input side:
→螺钉端子 Screw terminals M3.5
◆输出端 Output side:
→插片端子 Plug-in terminals 4.8×0.8mm
→电容插片端子 Plug-in terminals for capacitor 2.8×0.8mm

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
