◆可选带以下锁定类型 Optional with following lock types:
→闭合锁定和断电重启保护功能
→Lock-on and Restart Protection
→断开锁定带闭合锁定和断电重启保护功能
→Lock-off with lock-on and Restart Protection function
→可选带软启动功能 Optianal with Soft Start function
→可选带过流保护功能 Optianal with Over Current Protection
◆可选带以下附件 Optional with the accessories as follows:
→滤波电容(电容值由客户选定，一般为0.22μ F或0.33μF)
→Suppression capacitor (commonly 0.22or0.33μF)
→电缆线压线板和螺钉 Pressing Board for Cable and Screw

→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大冲击电流 Max. Inrush current at 250V96A
→最大冲击电流 Max. Inrush current at 127V132A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥100MOhm
→基本介电强度 Dielectric strength of function500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP50
→适用于II类防护器具 Suitable for appliances of protection class II

◆输入端 Input side:
→2×接线柱端子/螺钉M4 Pillar terminals φ=4mm with M4 Screw
◆输出端 Output side:
→2×插片端子Plug-in terminals 6.3×0.8mm
★本产品荣获实用新型专利，专利号：ZL201922091446.0
★Utility Model patented with the no. is ZL201922091446.0
