FA5-10A-A8

FA5-10A防尘快速动作扳机开关

FA5-10A series Dustproof Snap-action Trigger Switches

产品描述Product description

FA5-10A, FA5-10B系列是一款通用性的扳机开关,集成防尘功能内部为快速动作结构,适合一般功率的电动工具,如:型材切割机、斜切锯(介铝机)、125和150角磨机、电锤、电镐等。
FA5-10A, FA5-10B series are one general type trigger switch, integrated dustproof, with snap-action structure, for used in portable or bench top power-tools such as Cut-off Machines, Miter Saws, 125mm and 150mm Angle Grinders, Rotary Hammers, Demolition Hammers, etc.

产品特征Features

◆有多种支架和扳机可选 Optional with different supports and triggers
◆可选带以下锁定类型 Optional with following lock types:
→无锁 No Lock
→闭合锁定 Lock-on
→断开锁定 Lock-off

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大冲击电流 Max. Inrush current at 250V60A
→最大冲击电流 Max. Inrush currentat 125V90A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M  Ohm
→基本介电强度 Die lectric strength of function1500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II

端子类型Terminals

◆输入端/输出端 Input side/Output side:
→螺钉端子 Screw terminals M4

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
