产品描述Product description
◆FA1-10A 系列是一款通用性的大电流扳机开关，集成防尘功能，内部为快速动作结构，适合大功率的台式和手持式电动工具，如：型材切割机、斜切锯(介铝机)、150、180和230角向磨光机、抛光机、电圆锯、电锤、电镐、电链锯等。
◆FA1-10A series are general type high rated trigger switches,integrated dustproof, with snap-action structure, for used in high rated bench top or portable power-tools such as Cut-off Machines,Miter Saws, 150mm, 180mm and 230mm Large Angle Grinders, Polishers, Circular Saws, Rotary Hammers, Demolition Hammers, Electrics Chain Saws, etc.
产品特征Features
◆可选带以下功能 Optional with following function:
→双极常开 Double Pole Normally Open (DPNO)
→一极常开，另一极常闭 One Pole Normally Open, the other Normally Close
→单极双掷(常闭常开) (用极间连接片实现)
Single Pole Double Throw (SPDT)(with pole joint)
◆可选带以下附件 Optional with following accessories:
→带软胶扳机 Trigger covered with rubber (Overmolding)
→刹车连接片 Connection Piece for brake
◆可选带以下锁定类型 Optional with following lock types:
→无锁 No Lock
→闭合锁定 Lock-on
→断开锁定 Lock-off
→断开锁定带闭合锁定 Lock-off with lock-on
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大冲击电流 Max. Inrush current at 250V90A
→最大冲击电流 Max. Inrush current at 125V132A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→4×螺钉端子 Screw terminals M4 or M3.5
电气参数和认证 Electric Rating and Certification
