FA2-6CN-22X

FA2-6CN防尘扳机开关

FA2-6CN series Dustproof Trigger Switches

产品描述Product description

FA2-6CN系列是一款通用型的扳机开关,为FA2-6C系列的防尘改进款广泛应用于各类电动工具,如:型材切割机、斜切锯、云石机、电圆锯、电锤、电木铣、砂带机、砂光机、电刨等。
FA2-6CN series are one general type trigger switches, which is dustproof improved version of FA2-6C series, commonly for used in power tools such as Cut-off Machines, Miter Saws, Marble Cutters, Circular Saws, Electric Hammers, Electric Routers, Belt Sanders, Electric Planers, etc.

产品特征Features

◆可选带以下功能 Optional with following function:

→单极常开 SPNO

→单极双掷 SPDT

→双极常开 DPNO

→双极双掷 DPDT
→一极常开,另一极常闭 One Pole NO, the other NC
→一极常开,另一极双掷 One Pole NO, the other DT
◆可选带以下锁定类型 Optional with following lock types:
→无锁定 No Lock
→闭合锁定 Lock-on
→断开锁定 Lock-off

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大冲击电流 Max. Inrush current at 250V60A
→最大冲击电流 Max. Inrush current at 125V96A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M  Ohm
→基本介电强度 Dielectric strength of function1500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP50
→适用于II类防护器具 Suitable for appliances of protection class II

端子类型Terminals

◆输入端/输出端 Input side/Output side:
→接线柱端子 Pillar terminals φ=3.0mm

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
