◆可选带以下功能 Optional with following function:

→单极常开 SPNO

→单极双掷 SPDT

→双极常开 DPNO

→双极双掷 DPDT
→一极常开，另一极常闭 One Pole NO, the other NC
→一极常开，另一极双掷 One Pole NO, the other DT
◆可选带以下锁定类型 Optional with following lock types:
→无锁定 No Lock
→闭合锁定 Lock-on
→断开锁定 Lock-off

→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大冲击电流 Max. Inrush current at 250V60A
→最大冲击电流 Max. Inrush current at 125V96A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M  Ohm
→基本介电强度 Dielectric strength of function1500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP50
→适用于II类防护器具 Suitable for appliances of protection class II

◆输入端/输出端 Input side/Output side:
→接线柱端子 Pillar terminals φ=3.0mm
