FA2-6B-11-A0

FA2-6B防尘扳机开关

FA2-6B series Dustproof Trigger Switches

产品描述Product description

FA2-6B系列是一款通用型的扳机开关,集成防尘功能,广泛应用于各类电动工具,如:型材切割机、斜切锯、电圆锯、电锤等。
FA2-6B series are one general type trigger switch, integrated dust-proof, commonly for used in power tools such as Cut-off Machines, Miter Saws, Circular Saws, Electric Hammers, etc.

产品特征Features

◆可选带以下功能 Optional with following function:
→单极常开 SPNO
→单极双掷 SPDT
→一极常开,另一极直通 One Pole NO, the other Directly
→一极双掷,另一极直通 One Pole DT, the other Directly
◆可选带以下附件 Optional with the accessories as follows:
→包软胶扳机 Trigger covered with rubber (overmolding)

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大冲击电流 Max. Inrush current at 250V60A
→最大冲击电流 Max. Inrush current at 125V90A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M  Ohm
→基本介电强度 Dielectric strength of function1500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II

端子类型Terminals

◆输入端/输出端 Input side/Output side:
→接线柱端子 Pillar terminals φ=3.0mm

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
