产品描述Product description
◆FA1-6H系列是一款通用型的高额定扳机开关，有集成防尘功能主体，特别适用于直流电动工具和园林工具，如：直流电圆锯、直流电链锯、直流电动割草机、直流电动扫雪机等。
◆FA1-6H series are general type high rated trigger switch, have integrated dustproof version, special for used in DC power-tools and gardening tools such as DC Circular Saws, DC Electric Chain Saws, DC Electric Lawnmowers, DC Electric Snowthrowers, etc.
产品特征Features
◆可选带以下功能类型 Optional with following function types:
→单极常开 Single Pole Normally Open (SPNO)
→单极双掷 Single Pole Double Throw (SPDT)
→一极常闭，另一极常开
One Pole Normally Open, the other Normally Close
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大冲击电流 Max. Inrush current at 250V90A
→最大冲击电流 Max. Inrush current at 125V120A
→接触电阻 Contact resistance≤30m Oh m
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP40
→适用于II类防护器具 Suitable for appliances of protection class II
端子类型Terminals
◆输入端/输出端 Input side/ Output side:
→焊接端子 Soldering terminals
电气参数和认证 Electric Rating and Certification
