产品特征Features
◆本开关结构紧凑，可选带以下功能或附件：
→无刷电机专用电子调速功能
→智能调速功能,可选带软启动,欠压保护,过流保护,电池过温保护,电池过放保护,堵转保护等
→照明LED灯
→电池电量显示
→外接各类导线和电池夹
◆ The switches combine compact size, optional with the function or accessories as follows:
→Electronics variable speed con trol function
→Multi-function, optional soft start, under-voltage protection, over current protection, battery over temperature protection, Excessive discharge Protection or Locked-Rotor Protection, etc.
→LED Lighted
→Electric quantity of Battery display
→Auxiliary wire or battery clamp
技术数据Technical data
→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大电流 Max. current at 36Vd.c25A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function500V
→加强介电强度 Dielectric strength of reinforced500V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP40
◆开关内部电子部分在相应使用中一并做过相关测试，本开关适合做二类器具开关使用.
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
端子类型Terminals
◆输入端Input side:
→焊接端子 Solder terminal 4.8×0.8mm
◆输出端 Output side:
→焊接端子 Solder terminal 4.8×0.8mm
★本产品荣获实用新型专利，专利号：ZL202022763145.0
★Utility Model patented with the no. is ZL202022763145.0
