产品特征Features
◆可选带以下功能或附件：
→信号通断带电位器输出功能
→信号通断带正反转信号输出和电位器输出功能
→信号刹车
→带软胶扳机
◆ Optional with the function or accessories as follows:
→Signal On-off version with linear potentiometer
→Signal On-off version with Reversing and linear potentiometer
→Signal Brake
→Trigger covered with rubber (overmolding)
技术数据Technical data
→机械耐久寿命 Mechanical life endurance
≥5E4
→电气耐久寿命 Electrical life endurance
≥1E4
→最大电流 Max.current at 42Vd.c
0.1A
→接触电阻 Contact resistance
≤30m Ohm
→绝缘电阻 Insulation resistance
≥7M Ohm
→基本介电强度 Dielectric strength of function
500V
→加强介电强度 Dielectric strength of reinforced
500V
→环境温度 Ambient temperature
0°C~55°C
→阻燃等级 Flammability
UL 94V-0
→防护等级 Protection type
IP40
◆开关内部电子部分在相应使用中一并做过相关测试，本开关适合做二类器具开关使用.
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.
端子类型Terminals
◆输入端/输出端 Input side/Output side:
→导线端子 Wire terminal
→带插头导线端子 Wire terminal with Plug
★本产品荣获实用新型专利，专利号：ZL202121940125.4
★Utility Model patented with the no. is ZL202121940125.4
