DPK-R2-AN2-X(3+2)

DPK防尘直流扳机开关

DPK series Dustproof DC Trigger Switches

产品描述Product description

DPK系列是一款通用型的直流扳机开关,集成防尘机械刹车接点,内部带换向结构,应用于各类直流充电式手持电动工具,如:充电式电钻、充电式电锤、充电式电圆锯、充电式螺丝起子、充电式冲击扳手等,也可应用各类直流无刷电动工具。
DPK series are general type DC trigger switches, integrated dustproofmechanical brake conta ct and reversing box, commonly for used in DC cordless portable power-tools such as: Cordless Drills, Cordless Screw Drivers, Cordless Rotary Hammers, Cordless Impact Wrenches, etc. Besides, they also suitable for DC Cordless brushless DC tools.

产品特征Features

◆可选带以下功能或附件:
→通断带电位器输出功能
→通断带正反转信号和电位器输出功能(无刷直流电机专用)
→通断带正反转霍尔信号和电位器输出功能(无刷直流电机专用)
→可选带闭合锁定
→带软胶扳机
◆Optional with the function or accessory as follows:.
→On-off with linear potentiometer
→On-off with Reversing Signal and linear potentiometer output
(Special for DC brushless motor)
→On-off with Reversing Hall Signal and linear potentiometer output
(Special for DC brushless motor)
→Optional with Lock-on button
→Trigger covered with rubber (overmolding)

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大电流 Max. currentat 60Vd.c30A
→最大电流 Max. currentat 130Vd.c25A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambie nt temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP40
◆开关内部电子部分在相应使用中一并做过相关测试,本开关适合做二类器具开关使用.
◆ The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.

端子类型Terminals

◆输入端/输出端 Input side/Output side:
→焊接端子 Solder terminal 4.7×0.8mm
→沾锡导线 Wire with tin conductor
◆电位器输出 Potentiometer Output:
→沾锡导线 Wire with tin conductor
→带插头导线 Wire terminal with Plug
★本产品荣获多项实用新型专利,专利号:ZL201920301963.3,ZL201922101556.0
★Utility Models patented with the no. is ZL201920301963.3, ZL201922101556.0

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
