DFW series Dustproof DC Trigger Switches

产品描述Product description

DFW series are special type High-rated DC trigger switches, integrated dustproof, commonly for used in DC gardening power-tools such as: Cordless Blowers, Cordless Grass Trimmer, Cordless Multi-function Tools, etc. Besides, they also suitable for brushless DC tools.


◆可选带以下附件 Optional with the accessories as follows:
→外接二极管 Diode Externally
→外接各种联接导线 Auxiliary wire output
→带软胶扳机 Trigger covered with rubber (Overmoulding)

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命Electrical life endurance≥5E4
→最大电流 Max. current at 42Vd.c40A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥7M Ohm
→基本介电强度 Dielectric strength of function1300V
→加强介电强度 Dielectric strength of reinforced2600V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP50
◆The electronics in the switches had to be tested together with the corresponding appliances, so the switches are suitable for appliance of class II.


◆输入端/输出端 Input side/Output side:
→焊接端子 Solder terminal
→沾锡导线 Wire with tin conductor
◆电位器输出 Potentiometer Output:
→沾锡导线 Wire with tin conductor
→带插头导线 Wire terminal with Plug
★Utility Model patented with no. is ZL202121011840.X

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
