DR2-6E-2506E-C1X

DR2-6E交流转盘调速器

DR2-6E series AC Dial Wheel Speed Controls

产品描述Product description

DR2-6E系列是一款通用型的转盘电子调速器,是FR-6E系列的迷你版本,应用于各类手持电动工具,如:电锤、曲线锯、往复锯、100和125角向磨光机、,抛光机、搅拌器、电木铣、砂光机、模具电磨等。

DR2-6E series are one general type AC Dial Wheel Speed Controls, the mini-type of FR-6E series, for popular used in portable power-tools such as: Rotary Hammer, Jig Saws, Reciprocating Saws, 100mm and 125mm Angle Grinders, Polisher Grinders, Electric Routers, Sanders, Die Grinders, etc.

产品特征Features

◆可选带以下功能 Optional with following function:

→全波调速 Full-wave s peed control

→半波调速 Half-wave speed control

→On-Off通断功能带可变电阻输出 On-off version with Passive linear potentiometer

◆可选带以下附件 Optional with the accessories as follows:

→初始电压微调节旋钮 Knob for adjusting start voltage

→可控硅外置适合更大电流并可附带散热片

→External Triac version for high currents additional with heat sink

技术数据Technical data


→机械耐久寿命 Mechanical life endurance≥1E5

→电气耐久寿命 Electrical lifeendurance≥5E4

→最大电流 Max. current at 250V8A

→最大电流 Max. current at 125V12A

→接触电阻 Contact resistance≤30m Ohm

→绝缘电阻 Insulation resistance≥7M Ohm

→基本介电强度 Dielectric strength of function500V

→加强介电强度 Dielectric strength of reinforced3000V

→环境温度 Ambient temperature0°C~55°C

→阻燃等级 FlammabilityUL 94V-0

→防护等级 Protection typeIP40

→开关内部电子部分在相应使用中一并做过相关测试,本开关适合做二类器具开关使用。

→The electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class II.

端子类型Terminals

◆输入端/输出端 Input side/Output side:

→导线端子 Wires terminals AWG14 ~ AWG18.

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
