FA5-3E-A3

FA5-3E交流扳机调速开关

FA5-3E series AC Variable Speed (Trigger) Switches

产品描述Product description

FA5-3E系列是一款通用型扳机电子调速开关,广泛应用于各类小型手持式电动工具,如:电钻、电锤、曲线锯、脚踏调速开关等。
FA5-3E series are one general type variable speed trigger switches with by-pass contact, for popular used in portable power-tools such as: Electric Drills, Rotary Hammers, Jig Saws, Foot Variable Speed Switches, etc.

产品特征Features

◆可选带以下功能 Optional with following function:
→全波调速 Ful-wave speed control
→半波调速 Half- wave speed control
→三档位调速功能 Three Shift Variable Speed Function
◆可选带以下锁定类型 Optional with following lock types:
→无锁 No Lock
→闭合锁定 Lock-on
◆可选带以下附件 Optional with the accessories as follows:
→初始电压微调节旋钮 Knob for adjusting start voltage

技术数据Technical data

→机械耐久寿命 Mechanical life endurance≥1E5
→电气耐久寿命 Electrical life endurance≥5E4
→最大冲击电流 Max. Inrush current at 250V36A
→最大冲击电流 Max. Inrush current at 125V48A
→接触电阻 Contact resistance≤30m Ohm
→绝缘电阻 Insulation resistance≥100M Ohm
→基本介电强度 Dielectric strength of function1500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→防护等级 Protection typeIP40
→开关内部电子部分在相应使用中一并做过相关测试,本开关适合做二类器具开关使用。
→The electronics in the switches are to be tested together with the corresponding appliance, the switches are suitable for appliance of class II.

端子类型Terminals

◆输入端 Input side:
→接线柱端子 Pillar terminals φ=3mm
◆输出端 Output side:
→插入式端子可插入沾锡导线,带插片端子导线或铜包头导线
→Push-in terminals for soldered strands, strands with end sleeve or strands with end claws

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
