FA1-3S-A1

FA1-3S交流扳机开关

FA1-3S series AC Trigger Switch

产品描述Product description

FA1-3S系列是一款专用型扳机开关,集成防尘功能,带通断和电位器输出功能,可以和MK07调速线路板进行配套,应用于各类电动工具,如:150mm角磨机和抛光机等。开关扳机和锁钮可根据客户要求进行定制,线路板组件功能可以任意进行调节。
FA1-3S series are special type trigger switches, integrated dustproof, optional with MK07 PCB Assembly, for popular used in portable power-tools such as: 150mm Angle Grinders, Polisher Grinders, etc. The trigger and lock button can be make according to customer' 's request.

产品特征Features

◆可选带以下功能 Optional with following functions:
→On-Off通断功能 On-Off version
→0n-Off通断功能带线性电位器输出 On-off version with Passive linear potentiometer
◆可选带以下锁定类型 Optional with following lock types:
→无锁 No Lock
→闭合锁定 Lock-on

端子类型Terminals

◆输入端 Input side:
→接线柱端子 Pillar terminals φ=3mm
◆输出端 Output side:
→插入式端子可插入沾锡导线,带插片端子导线或铜包头导线
→Push-in terminals for soldered strands, strands with end sleeve or strands with end claws
◆线路板输出端 PCBA Outputside:
→导线端子 Wire leads

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
