MK06-2510SCP-S1

MK06交流软启动线路板组件

MK06 series AC PCB Assembly with Softstart

产品描述Product description

MK06系列是一款专用型线路板组件,具有软启动等功能,广泛应用于各类手持式电动工具,如:150和180角向磨光机、拋光机、型材切割机、斜切锯、水钻等。
MK06 series are one special type PCB Assembly, with soft start function, etc. Commonly for used in portable power-tools such as 150mm and 180mm Angle Grinders, Polisher Grinders, Cut-off ma chines, Miter Saws or Water Drills, etc.

产品特征Features

◆可选带以下功能 Optional following function types:
→断电重启保护功能 Restart Protection(X)
→软启动功能 Soft Start Function(S)
→过流保护功能 Over Current Protection Function(CP)
→过温保护功能 Over Temperature Protection Function(TP)

技术数据Technical data

→电气耐久寿命 Electrical life endurance≥5E4
→最大电流 Max. current at 250V15A
→最大电流 Max. current at 127V24A
→绝缘电阻 Insulation resistance≥7M  Ohm
→基本介电强度 Dielectric strength of function500V
→加强介电强度 Dielectric strength of reinforced3000V
→环境温度 Ambient temperature0°C~55°C
→阻燃等级 FlammabilityUL 94V-0
→适用于II类防护器具 Suitable for appliances of protection class II

端子类型Terminals

◆输入端/输出端 Input side/Output side:
→导线端子 Wire lead terminals

电气参数和认证 Electric Rating and Certification

订货信息Ordering Information
